Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex

Certificado
CHINA crown extra lighting co. ltd Certificações
CHINA crown extra lighting co. ltd Certificações
Estou Chat Online Agora

Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex

Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex
Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex

Imagem Grande :  Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex

Detalhes do produto:
Lugar de origem: Jiangsu, China
Marca: Crown Extra
Certificação: ATEX,CE,ROHS,CNEX,ISO9001
Número do modelo: Bhy
Condições de Pagamento e Envio:
Quantidade de ordem mínima: 1pc
Preço: USD40-60 per pc
Detalhes da embalagem: Caixa de madeira 、 Caixa de madeira 、 palete
Tempo de entrega: 15 dias úteis
Termos de pagamento: T/T.
Habilidade da fonte: 50000pcs/mês

Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex

descrição
Marca: Coroa extra Nome do produto: Luzes lineares à prova de explosão BHY
Habitação: aço Cri: RA: ≥70
Eficiência: 100lm/w Certificado: CNEX, EX, IP66, IEC, IECEX
CCT: 5500-6500K, outras temperaturas de cor podem ser personalizadas Ângulo do feixe: 120-140 °
Montagem: Tecto, parede, flange, pendente
Destacar:

explosion proof T8 LED tube

,

stainless steel fluorescent lamp

,

ATEX certified explosion proof light

Hot sales explosion-proof fluorescent lamp T8 LED tube 4ft with stainless steel enclosure 5 Years Warranty Atex



BHY Series

Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex 0



Features:

1. SMC mold pressure shell, high strength, impact resistance, corrossion proof. Lampshade is formed by polycarbonate injection molding, high transmittance, strong ability to withstand shocks.
2. Lamp is adopts curve sealed structure, high waterproof and dust proof class.
3. Lightweight and slim line construction
4. The emergency device can be equipped at the request of users, when the emergy power supply breaks, the fluorescent with emergency unit can switch to emergency lighting state automatically




Applications


A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation
Other high humidity, high dust, high temperature, vapor locations




Standard Materials
Housing: Steel plate, Stainless steel optional
Exterior: Stainless steel
Globe: Polycarbonate, anti-glare
Gasket: Silicon rubber




Certifications
ATEX
CNEX
CE
RoHS
ISO9001





Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex 1







Electrical Data
Ex Marking Ex d e IIC T6
Classification Class I, Division 1 and 2,Group A,B,C,D; ZONE1 ZONE21 AND 22
IP Degree IP66
Corrosion Resistant WF2
Input Voltage 220VAC, 50/60 Hz
Battery Back-up Optional, Emergency time>90min;Charging time:24h;Starting time:0.3s
Power Factor 0.98
Conduit Entries G 3/4"
Mounting Styles Pendant; Ceiling; Chain; Embedded; Wall; Stanchion




Ordering Information

Model No. BHY BHY-Tri tube
T8 Fluorescent tube 2*40W 3*40W
T5 Fluorescent tube 2*28W 3*28W
LED tube 2*18W 3*18W




Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.



Explosion Proof Fluorescent Lamp T8 LED Tube 4ft With Stainless Steel Enclosure 5 Years Warranty Atex 2
