Casa ProdutosLuz fluorescente à prova de explosões

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex

Certificado
CHINA crown extra lighting co. ltd Certificações
CHINA crown extra lighting co. ltd Certificações
Estou Chat Online Agora

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex
Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex

Imagem Grande :  Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex

Detalhes do produto:
Lugar de origem: Jiangsu, China
Marca: Crown Extra
Certificação: ATEX,CE,ROHS,CNEX,ISO9001
Número do modelo: Bys
Condições de Pagamento e Envio:
Quantidade de ordem mínima: 1pc
Preço: USD32-40 per pc
Detalhes da embalagem: Caixa de madeira 、 Caixa de madeira 、 palete
Tempo de entrega: 15 dias úteis
Termos de pagamento: T/T.
Habilidade da fonte: 50000pcs/mês

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex

descrição
Marca: Coroa extra Nome do produto: Luzes lineares à prova de explosão BYS
Habitação: Poliéster reforçado com fibra de vidro Cri: RA: ≥70
Eficiência: 100lm/w Certificado: CNEX, EX, IP66, IEC, IECEX
CCT: 3000/4000/5000/5700K, outras temperaturas de cor podem ser personalizadas Ângulo do feixe: 120-140 °
Exterior: Aço inoxidável

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex





BYS Series



Features:

1.GRP enclosure, corrosion-proof, Polycarbonate lampshade, strip-shaped with anti-glare
2.Special locking mechanism, with reliable locking force
3.Built-in explosion proof interlockdevice, automatically power-off after cover open
4.The emergency device can be equipped




Applications


A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation
Other high humidity, high dust, high temperature, vapor locations




Standard Materials
Housing:
Fiber-glass reinforced polyester
Exterior:Stainless steel
Globe:
Polycarbonate, anti-glare
Gasket:Silicon rubber




Certifications
ATEX
CNEX
CE
RoHS
ISO9001



Electrical Data
Ex Marking
Ex d e IIC T6 Gb/ DIP A21 TA
Classification
Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D;
IP DegreeIP66
Corrosion ResistantWF2
Rated Voltage
110VAC; 220VAC/50~60HZ
Battery Back-up
Optional, Emergency time>90min;Charging time:24h;Starting time:0.3s
Conduit EntriesG 3/4"
Terminal≤2.5mm2
Mounting Styles
Pendant; Ceiling; Chain; Embedded; Wall; Stanchion




Ordering Information
Model NO.BYS-600BYS-1200
T8 Fluorescent tube
(1-3)*18Watt (1350Lm,75Lm/W)
(1-3)*36Watt (2700Lm,75Lm/W)
T5 Fluorescent tube
(1-3)*14Watt(1350Lm,96Lm/W)
(1-3)*28Watt (2100Lm,75Lm/W)
LED tube
(1-3)*8Watt (800Lm,100Lm/W)
(1-3)*18Watt (1800Lm,100Lm/W)



Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex 0
Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex 1


Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.

Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex 2Factory Supply 18w 27w 36w Linear Led Explosion Proof Light 1.2m 100lm/w 110VAC IP66 5 Years Warranty Atex 3
